C77 Overhead Blackout Unit Electric

PART NO C77

C77 Overhead Blackout Unit Electric

100% blackout at the touch of a button. The quiet and reliable 230v AC Yewdale motor is housed within the barrel and supported by a sturdy, aluminium cassette system. Perfect for roof or sloping windows in awkward or inaccessible locations.  Comes as standard with black powder-coated hardware with heavy-duty componentry and powerful spring tensioning.  Blackout fabric, side channels, baffles and pile-seals stop any light filtering through.

  • 230v AC Yewdale motor
  • Ideal for roof/sloping windows
  • Option of remote control

Downloads

Benefits

The YewdaleDefiant® C77 electric overhead blackout unit with a Yewdale motor.

All hardware in black powder-coated aluminium for face or recess fixing and enclosing 53mm and 57mm grooved aluminium barrels.

The blackout fabric is locked into a groove in the barrel and the heavy-duty bottom rail and runs in 75mm side channels.

Light-transfer baffles are within the side and bottom channels.

Side channels and head-box are fitted with pile-seal for light sealing.

Fabric is mounted onto a sprung 57mm aluminium barrel whilst at the other end, it is fitted to an aluminium bottom rail which is attached to two draw tapes. These tapes are attached, between flanged guides, to the 53mm drive barrel, operated by a 230v AC Yewdale motor.

Options

  • White hardware
  • Remote and/or group control systems
  • Available in any RAL colour

Specification

The YewdaleDefiant® C77 electric overhead blackout unit with 230v AC Yewdale motor as manufactured by Yewdale, +44 (0)1268 570900. Flame retardant blackout fabric from the YewdaleDefiant® range, on 57mm aluminium barrel with enclosed spring attached to aluminium bottom rail as standard. 53mm drive barrel connected to gear control crank mechanism operates the blind by means of draw-tapes to the bottom bar. Black/white powder-coated aluminium head-box cassettes, side and bottom channels and bottom bar. Incorporating 230v AC Yewdale motor

Code Description Min Width Max Width Max Drop Max m2
C77 C77 Overhead Electric Blackout Unit 720 2000 2600 4.2

Based on fabric weight of 400g/m², e.g. Dart. Larger sizes may be possible with lighter/thinner fabrics. Sizes shown in millimetres unless otherwise specified.

Dim Out
Black Out
Screen
Fire Retardancy
Suitable for roller blinds
Suitable for vertical blinds
Anti Bacterial
Wipe Clean
Wipe with damp sponge
Suitable for moist conditions
100% Polyester

Dim Out

Black Out

Screen

Fire Retardancy

Suitable for roller blinds

Suitable for vertical blinds

Anti Bacterial

Wipe Clean

Wipe with damp sponge

Suitable for moist conditions

100% Polyester

System Components

Product Details

Benefits

The YewdaleDefiant® C77 electric overhead blackout unit with a Yewdale motor.

All hardware in black powder-coated aluminium for face or recess fixing and enclosing 53mm and 57mm grooved aluminium barrels.

The blackout fabric is locked into a groove in the barrel and the heavy-duty bottom rail and runs in 75mm side channels.

Light-transfer baffles are within the side and bottom channels.

Side channels and head-box are fitted with pile-seal for light sealing.

Fabric is mounted onto a sprung 57mm aluminium barrel whilst at the other end, it is fitted to an aluminium bottom rail which is attached to two draw tapes. These tapes are attached, between flanged guides, to the 53mm drive barrel, operated by a 230v AC Yewdale motor.

Options

  • White hardware
  • Remote and/or group control systems
  • Available in any RAL colour

Specification

The YewdaleDefiant® C77 electric overhead blackout unit with 230v AC Yewdale motor as manufactured by Yewdale, +44 (0)1268 570900. Flame retardant blackout fabric from the YewdaleDefiant® range, on 57mm aluminium barrel with enclosed spring attached to aluminium bottom rail as standard. 53mm drive barrel connected to gear control crank mechanism operates the blind by means of draw-tapes to the bottom bar. Black/white powder-coated aluminium head-box cassettes, side and bottom channels and bottom bar. Incorporating 230v AC Yewdale motor

Min Width: 720

Max Width: 2000

Max Drop: 2600

Max m2: 4.2

Based on fabric weight of 400g/m², e.g. Dart. Larger sizes may be possible with lighter/thinner fabrics. Sizes shown in millimetres unless otherwise specified.

Fabric Options

Dim Out
Black Out
Screen
Fire Retardancy
Suitable for roller blinds
Suitable for vertical blinds
Anti Bacterial
Wipe Clean
Wipe with damp sponge
Suitable for moist conditions
100% Polyester

Dim Out

Black Out

Screen

Fire Retardancy

Suitable for roller blinds

Suitable for vertical blinds

Anti Bacterial

Wipe Clean

Wipe with damp sponge

Suitable for moist conditions

100% Polyester

System Components

System Components
