Benefits
The YewdaleDefiant® C57T overhead electric cassette blind comes with a 230v AC Tubular Motor as standard.
At the touch of a button from the remote switch (sold separately), the blind can open and close, shading ceiling windows with ease.
This overhead cassette blind is quietly drawn across the window by tensioned spring units.
The fabric is neatly held in place and remains taut by the side channels.
The powder-coated aluminium headbox is available in a square or rounded profile, providing a discreet and stylish solution for overhead shading.
This blind is bracket less which eliminates light seepage and is simpler to install in comparison to other overhead blinds.
The C57T can be made to a maximum size of 3m X 3m.
We recommend the YewdaleDefiant® SkyShelf for optimum installation within a recess.
Options
- Black or white hardware
- Square or rounded headbox
- Hard-wired or RTS motor
- We recommend the YewdaleDefiant® SkyShelf to ensure the blind is fitted squarely in a recess.
- It is recommended that only Roach is used on this system. Please note, this systems tension box will provide a pinging sound during operation. Some rippling may occur at the edges of the fabric.
Specification
The YewdaleDefiant® C57-90/120T electric overhead cassetted blind with Tracker Fabric Retaining System as manufactured by Yewdale, +44 (0)1268 570900. Flame retardant fabric from the YewdaleDefiant® range, on a grooved 53/70mm aluminium barrel along with aluminium bottom bar as standard. The barrel, driven by a 230v AC motor, operates the blind by means of tensioned spring units connected to the bottom bar. Twin black/white powder-coated aluminium headbox cassettes, side and bottom channels and bottom bar. Some rippling may occur at the edges of the fabric.
Find this product on NBS Source
Cassette size (HxD): 105x95mm**140x120mm
Barrel Size Ø: 53mm**53/70mm
Side Channel Size (WxD): 50x24.8mm*50x24.8mm
| C57-90T recess size width minus 2mm & drop minus 2mm = Blind size minus 89mm = fabric width |
| C57-120T recess size width minus 2mm & drop minus 2mm = Blind size minus 89mm = fabric width |
| C57-90TS recess size width minus 14mm & drop minus 14mm = Blind size minus 89mm = fabric width |
| C57-120TS recess size width minus 14mm & drop minus 14mm = Blind size minus 89mm = fabric width |
