R20D Double Roller Blind with Sidewinders

PART NO R20D

R20D Double Roller Blind with Sidewinders

A versatile double roller that allows for two different fabric styles or colours to cover one window. The barrels are held with a sturdy metal bracket, with the double spring action and metal control chain providing a smooth operation. Available with a range of bottom bars.

40/45mm barrel diameters
Metal control chains
Double roller for different fabric styles and colours

Enquire Now Request a quote

Downloads

Datasheet

Product Details Fabric Options System Components

Benefits

The versatility of the R20D makes it first choice for a vast range of applications. With the double roller mechanism it allows for different fabric styles or colours to cover one window. Vandal resistant features includes Slipstream^®: a friction reducing technology - smooth action operation, air cooled design and double spring function - providing you with enhanced hold, exceptional long life properties and advanced chain loading. Metal control chain, fabric locked into the barrel and bottom bar, and sturdy, attractive metal brackets with covers.

Options

Bracket covers; 1:4 Geared mechanism; Plastic control chain; Alternative bottom bars including fully fabric covered in aluminium or plastic, Round aluminium in white or silver and Teardrop aluminium in black, silver or white; Wire side-guiding system; White aluminium back bar; Channel side-guiding system.

Specification

The YewdaleDefiant^® R20D double roller blind incorporating Slipstream^® Technology for enhanced hold, advanced loading and exceptional long life properties as manufactured by Yewdale, +44 (0)1268 570900. Flame retardant fabric from the YewdaleDefiant^® range, locked into grooved 40/45mm aluminium barrel along with white plastic bottom bar. Metal control chain and white plastic bracket covers.

Find this product on NBS Source

Code	Description	Min Width	Max Width	Max Drop	Max m²
R20D	R20D Double roller	200	2650	3350	6.5

R20D recess size width minus 2mm = blind size width minus 37mm = fabric width
