KR20C Anti ligature Roller Blind with Crank - Yewdale

KR20C Crank

PART NO KR20C

KR20C Crank

Safe, durable and ideal for mental health settings. With a detachable magnetic crank, the load release roller blind is tamper-proof and safe for areas where cords would be a problem. Comes with a 45mm barrel, white magnetic anti-ligature brackets for wall or top fixing and a robust 1:5 crank mechanism.

  • Magnetic detachable handle
  • Range of bottom bar styles
  • Supplied with anti-ligature brackets

Downloads

Benefits

Durability and simplicity make the KR20C load release roller blind a good choice for a vast range of applications. The magnetic detachable crank ensures the blind is vandal-resistant and safe for areas where cords are a threat.

The fabric is locked into the barrel and bottom bar, supported by sturdy metal brackets and fitted to a white aluminium back bar, secured by magnetic brackets for 100% fail-safe anti-ligature functionality.

Select your ideal fabric colour from the flame retardant YewdaleDefiant fabric range.

Options

  • Bracket covers
  • Alternative bottom bars including fully fabric covered in aluminium or plastic, and aluminium teardrop in black or silver
  • Fixed crank handle.

Specification

The magnetic anti-ligature YewdaleKestrel® KR20C crank control roller blind with magnetic detachable crank handle as manufactured by Yewdale, +44 (0)1268 570900. Flame retardant fabric from the YewdaleDefiant® range, locked into grooved 45mm aluminium barrel along with white Tear Drop aluminium bottom bar. Robust vandal resistant 1:5 crank mechanism with pin end supported by white metal brackets and fitted to white aluminium back bar, secured by magnetic wall-fix / top-fix brackets spaced in accordance with manufacturers recommendations. Fitting to be carried out by trained and accredited personnel.

Find this product on NBS Source



O+M Guidance

It is an NHS requirement that items suspended on load-release support systems should be maintained and load-tested on an annual basis in accordance with the manufacturer’s instructions. It is a requirement to carry out a physical inspection and testing of YewdaleKestrel® fittings to identify any possible damage or evidence of tampering and undertake an annual load test. All installations require a commission pull test to be carried out and recorded and copy given to the client to sign off the installation.

A clear inspection and repair and/or replacement policy should be followed ensuring that components have not become redundant or worn or superseded by safer systems. Tests, including load tests, carried out on components should not affect the integrity and reliability of the components and parts should not need to be replaced each time a test is carried out.

Annual inspection and load testing of YewdaleKestrel® systems should only be carried out by Protects Plus 0345 646 0955.

Safety Note

Sensitive electronic equipment may be damaged by proximity to a magnetic field and should not come within 150mm of the underside of the brackets. Any load-release device, by its nature, may cause damage when operated. Articles suspended from the YewdaleKestrel® magnetic anti-ligature system will come down when pulled.

YewdaleKestrel® products are designed as standalone products only. Care should be taken when assessing or arranging a room to ensure that YewdaleKestrel® products cannot be misused in conjunction with any other item, furniture or fixings in the room. It is the responsibility of the end user or client to ensure the product is suitable for the environment it is being installed in. YewdaleKestrel® products must be fitted by a qualified professional following the manufacturer’s instructions. Failure to do so could jeopardise the product’s effectiveness as an anti-ligature system.

Code Description Min Width Max Width Max Drop Max m2
KR20C Crank 200 2000 3300 5

Based on fabric weight of 220g/m², e.g. Thames. Sizes shown in millimetres unless otherwise specified. Use of heavier fabrics may require appropriate reductions. Where adjacent YewdaleKestrel® blinds are fitted, there should be no more than 2 brackets within a total distance of 700mm.

Dim Out
Black Out
Screen
Fire Retardancy
Suitable for roller blinds
Suitable for vertical blinds
Anti Bacterial
Wipe Clean
Wipe with damp sponge
Suitable for moist conditions
100% Polyester

Dim Out

Black Out

Screen

Fire Retardancy

Suitable for roller blinds

Suitable for vertical blinds

Anti Bacterial

Wipe Clean

Wipe with damp sponge

Suitable for moist conditions

100% Polyester

Product Details

Benefits

Durability and simplicity make the KR20C load release roller blind a good choice for a vast range of applications. The magnetic detachable crank ensures the blind is vandal-resistant and safe for areas where cords are a threat.

The fabric is locked into the barrel and bottom bar, supported by sturdy metal brackets and fitted to a white aluminium back bar, secured by magnetic brackets for 100% fail-safe anti-ligature functionality.

Select your ideal fabric colour from the flame retardant YewdaleDefiant fabric range.

Options

  • Bracket covers
  • Alternative bottom bars including fully fabric covered in aluminium or plastic, and aluminium teardrop in black or silver
  • Fixed crank handle.

Specification

The magnetic anti-ligature YewdaleKestrel® KR20C crank control roller blind with magnetic detachable crank handle as manufactured by Yewdale, +44 (0)1268 570900. Flame retardant fabric from the YewdaleDefiant® range, locked into grooved 45mm aluminium barrel along with white Tear Drop aluminium bottom bar. Robust vandal resistant 1:5 crank mechanism with pin end supported by white metal brackets and fitted to white aluminium back bar, secured by magnetic wall-fix / top-fix brackets spaced in accordance with manufacturers recommendations. Fitting to be carried out by trained and accredited personnel.

Find this product on NBS Source



O+M Guidance

It is an NHS requirement that items suspended on load-release support systems should be maintained and load-tested on an annual basis in accordance with the manufacturer’s instructions. It is a requirement to carry out a physical inspection and testing of YewdaleKestrel® fittings to identify any possible damage or evidence of tampering and undertake an annual load test. All installations require a commission pull test to be carried out and recorded and copy given to the client to sign off the installation.

A clear inspection and repair and/or replacement policy should be followed ensuring that components have not become redundant or worn or superseded by safer systems. Tests, including load tests, carried out on components should not affect the integrity and reliability of the components and parts should not need to be replaced each time a test is carried out.

Annual inspection and load testing of YewdaleKestrel® systems should only be carried out by Protects Plus 0345 646 0955.

Safety Note

Sensitive electronic equipment may be damaged by proximity to a magnetic field and should not come within 150mm of the underside of the brackets. Any load-release device, by its nature, may cause damage when operated. Articles suspended from the YewdaleKestrel® magnetic anti-ligature system will come down when pulled.

YewdaleKestrel® products are designed as standalone products only. Care should be taken when assessing or arranging a room to ensure that YewdaleKestrel® products cannot be misused in conjunction with any other item, furniture or fixings in the room. It is the responsibility of the end user or client to ensure the product is suitable for the environment it is being installed in. YewdaleKestrel® products must be fitted by a qualified professional following the manufacturer’s instructions. Failure to do so could jeopardise the product’s effectiveness as an anti-ligature system.

Min Width: 200

Max Width: 2000

Max Drop: 3300

Max m2: 5

Based on fabric weight of 220g/m², e.g. Thames. Sizes shown in millimetres unless otherwise specified. Use of heavier fabrics may require appropriate reductions. Where adjacent YewdaleKestrel® blinds are fitted, there should be no more than 2 brackets within a total distance of 700mm.

Fabric Options

Dim Out
Black Out
Screen
Fire Retardancy
Suitable for roller blinds
Suitable for vertical blinds
Anti Bacterial
Wipe Clean
Wipe with damp sponge
Suitable for moist conditions
100% Polyester

Dim Out

Black Out

Screen

Fire Retardancy

Suitable for roller blinds

Suitable for vertical blinds

Anti Bacterial

Wipe Clean

Wipe with damp sponge

Suitable for moist conditions

100% Polyester
